Telescopic wheel loader 1622 T

Standard equipment telescopic wheel loader 1622 t

Engine
- Type: 3-cylinder diesel engine Kubota D902, 16.2 kW (22 HP)
- Output: 16,2 kW (22 HP)
- Exhaust gas treatment / emission level: - / V
Tyres
- Standard tyres: 23x8.5-12 AS
- Option I: 23x8.5-12 SKD/MultiTrac
- Option II: 23x10.5-12 AS/MultiTrac
Electric system
- Operating voltage: 12 V
Dimensions
- (A) Wheelbase: 1,345 mm
- (B) Chassis length: 2,585 mm
- (C) Overall length with standard bucket: 3,150 mm
- (D) Digging depth: 80 mm
- (E) Reach: 1,400 mm
- (F) Swivelling point, telescopic arm retracted: 2,830 mm
- (G) Loading height with pallet forks: 2,580 mm
- (H) Max. dumping height: 1,940 mm
- (I) Front end height: 1,390 mm
- (J) Dumping width: 405 mm
- (K) Seat height: 1,010 mm
- (L) Protective roof height: 1,990 mm
- (M) Max. bucket pivot point: 2,320 mm
- (N) Overall width: 890 / 1,060 mm
- (O) Inner turning radius: 970 mm
- (P) Outer turning radius: 1,875 mm
- (Q) Outer radius with standard bucket: 2,290 mm

Drive
- Traction hydraulics: Hydrostatic-automotive
- Axles: Original Schäffer axles, 5 wheel nut rim
- Speed: 16 km/h
Brakes and steering
- Service braking system: Hydrostatic
- Parking brake: Mechanical drum brake
- Steering: Fully hydraulic articulated-swivel steering
Tank capacity
- Fuel: 25 l
- Hydraulic oil: 22 l

Working hydraulics
- Delivery rate / option: 28 l/min
- Operat. pressure: 200 bar
Weights
- Operating weight protective roof incl. Original tyres, driver and standard bucket: 1,400 kg
- Lifting capacity: 810 kg
- Tipping load, straight, pallet fork acc. to ISO 8313: 550 kg
- Tipping load, straight, bucket acc. to ISO 8313: 710 kg
Sounds and vibration
- Sound pressure level LpA: 84 db(A)
- Sound power level guaranteed LwA: 101 db(A)
- Sound power level equivalent LwA: 100 db(A)
- Hand/arm vibration acc. to ISO 8041: < 2.5 m/s²
- Total body vibration acc. to ISO 8041: < 0.5 m/s²
